Product information "Super Vac - V18-ES Valor Series Electric PPV"
Compact, rugged, and firefighting-ready. The Super Vac V18-ES brings high-performance ventilation in a portable format—built with the familiar Valor frame and engineered to tackle ventilation in both residential and commercial scenarios.
Key Features & Benefits
Durable Valor Frame Construction
Made with a full roll-cage aluminum frame that’s 15% lighter than steel, this unit resists impacts and simplifies on-scene positioning.Powerful Electric Performance
Equipped with a 1 HP Bluffton (TEAO) motor, delivering consistent and reliable output with minimal maintenance.Heat-Resistant Fan Blade
A seven-point cast aluminum airfoil blade withstands extreme temperatures where plastic alternatives fail.Optimized Airflow Design
Features a precision-spun steel shroud with a standard StreamShaper guard—allowing for extended setback performance. An optional Air Cone Guard is also available.Full Directional Control
The foot-activated seven-position tilt frame enables angles from downward blasts to upward ventilation—perfect for navigating stairs or gaps.Easy Handling & Transport
Fold‑down ergonomic handle fits gloved hands and stows compactly.
Flat-proof rubber tires make deployment across stairs and debris seamless, and are placed to ensure firefighters never position themselves between the fan and a hazard.
Certified Airflow Output
Tested to AMCA 240 standards, the V18‑ES delivers 6,378 CFM (≈10,836 CMH) airflow at a 9 ft setback with a 13° tilt.Resource-Efficient Power Requirements
Requires a 4,000 W start on a standard 15-amp circuit—dropping to a 1,500 W running load.Compact Footprint for Tight Spaces
Dimensions are approximately 23.5″ H × 22″ W × 21″ D (600 × 560 × 535 mm); weight stands at 80 lb (36 kg).Built to Last
Complete with a 5-year unit warranty, giving departments long-term reliability and value.
Technical Specifications
| Specification | Details |
|---|---|
| Blade Diameter | 18″ airfoil (cast aluminum) |
| Motor | 1 HP Bluffton/Leeson TEAO electric |
| RPM | Approximately 1,750–1,783 RPM |
| Airflow (AMCA 240) | 6,378 CFM (10,836 CMH) |
| Setback Rating | 9 ft (2.7 m) |
| Tilt Angle (Tested) | 13° |
| Dimensions (HxWxD) | 23.5″ × 22″ × 21″ (600 × 560 × 535 mm) |
| Weight | 80 lb (36 kg) |
| Start Power | 4,000 W (15 A circuit) |
| Run Power | 1,500 W |
| Warranty | 5 years (unit) |
