3M™ Scott™ - V320 Thermal Imager
Product information "3M™ Scott™ - V320 Thermal Imager"
3M™ Scott™ V320 Thermal Imager
Mission-Critical Imaging in the Palm of Your Hand
Designed with input from firefighters, the 3M™ Scott™ V320 Thermal Imager delivers high-performance thermal vision in a compact, easy-to-use design. Whether navigating smoke-filled structures or identifying hot spots, the V320 helps firefighters make faster, safer decisions in extreme conditions.
Key Features:
320x240 High-Resolution Sensor
Provides crisp, detailed thermal imaging to improve situational awareness in low-visibility environments.Fast Startup Time
Powers on in under 5 seconds—no standby mode required—so it’s ready when you are.Extended Runtime
Rechargeable lithium-ion battery provides up to 8 hours of continuous operation.3.5" High-Contrast Display
Bright, easy-to-read LCD ensures visibility in a wide range of lighting conditions.Single-Button Operation
Intuitive, glove-friendly interface—no menus or complex navigation needed during high-stress calls.Lightweight and Rugged
Weighing under 2.2 lbs (1 kg), the V320 is built to withstand drops, extreme heat, water ingress (IP67 rated), and other hazards of the fireground.Ergonomic Design
Balanced for use in either bare or gloved hands, improving comfort and usability.
Advanced Imaging Specs:
Field of View: 55° horizontal / 42° vertical
Image Frequency: >25 Hz (9 Hz option also available)
Dynamic Range: –20 °C to +650 °C
NETD: <70 mK typical (@25 °C); <100 mK max
Accuracy: ±5 °C or 5% (typical), up to ±10 °C or 10% (max)
Durability & Certification:
Drop Tested: Survives 6.6 ft (2 m) drops to concrete
Ingress Protection: IP67 rated
Environmental Testing: Conforms to IEC standards for shock, vibration, thermal cycling, and salt spray corrosion
Optional Add-ons:
Desktop Charger
Spare Rechargeable Batteries
Retractable Lanyard
Shipping Restriction: This product can only be shipped within New Hampshire, Massachusetts, and Maine due to manufacturer territory agreements. For more information or assistance, please contact us directly.
| Category: | Thermal Cameras |
|---|
